JUMO hydroTRANS S20

Product number: 802109

€330.10*

Please log in to receive your conditions.

Prices excl. VAT plus shipping costs.

Show gross prices
(incl. VAT)

Available, delivery time:

Version

Measuring range(s): 0 ... 95 % rH / -10 ... +60 °C / 10,000 ppm, Output: RS-485 Modbus

Measuring range(s): 0 ... 95 % rH / -10 ... +60 °C / 10,000 ppm, output: 4 ... 20mA / 0 ... 10V combi output configurable

Measuring range(s): 0 ... 95 % rH / -10 ... +60 °C / 10,000 ppm, output: 4 ... 20mA / 0 ... 10V combi output configurable, extra code: with integrated display

Measuring range(s): 0 ... 95 % rH / -10 ... +60 °C / 10,000 ppm, output: RS-485 Modbus, extra code: with integrated display

Measuring range(s): 0 ... 95 % rH / -10 ... +60 °C / 10,000 ppm, output: SPE with PoDL (Modbus TCP slave), extra code: with integrated display

Measuring range(s): 0 ... 100 % rH / -40 ... +80 °C, output: 4 ... 20mA / 0 ... 10V combi output configurable

Measuring range(s): 0 ... 100 % rH / -40 ... +80 °C, output: 4 ... 20mA / 0 ... 10V combi output configurable, extra code: with integrated display

Measuring range(s): 0 ... 100 % rH / -40 ... +80 °C, output: RS-485 Modbus

Measuring range(s): 0 ... 100 % rH / -40 ... +80 °C, output: RS-485 Modbus, extra code: with integrated display

Product number: 802109

GTIN: 4068823016734

Offer as PDF
Login for addressed offer The entered number of pieces will be taken into account when creating the offer.

Product information "JUMO hydroTRANS S20 "

JUMO hydro TRANS S20 - Humidity and temperature transmitter with optional wall-mounted CO2 module

Typ: 907042/12-0-17-530/000

Basic type extension: RH-T-CO2
Version: Standard
Measuring range: 0 ... 95 % rH / -10 ... +60°C / 10.000 ppm
Output: RS-485 Modbus
Extra code: without
Measuring parameters: Temperature, relative humidity, carbon dioxide (CO2) optional
Interfaces: USB, RS485, Sigle Pair Ethernet (SPE)
Robustness
Easy to install
Multi-sensor
Optional plastic sintered filter

The humidity and temperature transducer monitors the quality of the ambient air and can be wall-mounted both indoors and in protected outdoor areas.

Areas of application

Climate monitoring
Ventilation systems
Building management
Storage rooms

Other attributes

Ausgang	RS485 Modbus
Customs tariff number	90258040
Messbereich (Temperatur & relative Feuchte)	0...95% rF / -10°C...+60°C
Messparameter	Kohlenstoffdioxid (CO2), Relative Feuchte, Temperatur

Downloads:

JUMO hydroTRANS S20 907042.pdf

Technical data:

Electrical safety

Requirements

DIN EN IEC 61010-1:2020

The device must be supplied with an electrical circuit that meets the requirements for "energy-limited circuits".

Electric Dating

Device with analogue output

Power supply	DC 24 V, -33 %/+33 %, SELV, PELV
Power consumption	≤ 2,4 W
Surge Category	II
Degree	2
Class	DIN EN 61140, Class III (Protective extra-low voltage)
Electrical connection Connection Elements	Spring clamb
Connection cable cable cable cross-section Without ferrule With ferrule Stripping length Without ferrule With ferrule Temperature resistance	AWG 28 bis AWG 14
	0,2 to 1,5 mm²
	0,25 to 1,5 mm²
	8 mm
	10 mm
	≥ 80 °C

Device with RS485

Power supply	DC 24 V, -58 %/+33 %, SELV, PELV
Power consumption	≤ 2,4 W
Surge Category	II
Degree	2
Class	DIN EN 61140, Class III (Protective extra-low voltage)
Electrical connection Connection Elements	Spring clamb
Connection cable cable cable cross-section Without ferrule With ferrule Stripping length Without ferrule With ferrule Temperature resistance	AWG 28 to AWG 14
	0,2 to 1,5 mm²
	0,25 to 1,5 mm²
	8 mm
	10 mm
	≥ 80 °C

Device with SPE

Power supply	DC 18 to 30 V, PELV
Power consumption	≤ 100 mA
Power consumption	≤ 1,8 W
Surge Category	II
Degree	2
Class	DIN EN 61140, Class III (Protective extra-low voltage)
PoDL-Class	Class 11, IEEE 802.3cg
PoDL-Classification	SCCP- oder Forced-Mode
Electrical connection Connector	M12-Plug connection
M12 Connectors	IEC 63171-5
Execution	2-polig, shielded
Protection	IP67
Trunk	IEC 61156-13, IEC 61156-14
Execution	2-adrig, Kupfer, shielded
Bandwidth	≥ 20 MHz
Length	≤ 500 m (AWG22 bei DC 24 V)
DC Loop Resistor	< 59 Ω
Temperature resistance	≥ 80 °C

Inputs

Measuring range

Relative residual moisture

Measuring range With CO2 module	0 to 100 % RH 0 to 95 % RH
Accuracy
Typical	±2,0 % RH
Max.	±2,5 % RH
Measurement Rate	1 s

Temperature

Measuring range With CO2 module	-40 to +80 °C -10 to +60 °C
Genauigkeit
Typical	±0,2 °C
Max.	±0,4 °C
Measurement Rate	1 s

Carbon dioxide (CO2)

Optional on devices with analog output and RS485, factory on devices with SPE.

Measuring range

400 to 10000 ppm

Accuracy Reference Conditions

Ambient temperature Air Pressure Humidity

Measuring range

±(50 ppm + 5 % from the measured value)

25 °C

1013 hPa

50 % RH

400 to 1 000 ppm

Measurement Rate

30 s

Exits

Device with analogue output

Power Output

Signal Range	4 to 20 mA
Output Signal Limits	0 to 22 mA
Accuracy	≤ ±0,05 % related to end of signal range (20 mA)
Temperature	±50 ppm/K
Burden Influence	≤ ±0,02 % pro 100 Ω
Burde	≤ 500 Ω

Voltage output

Signal Range	0 to 10 V
Output Signal Limits	0 to 11 V
Accuracy	≤ ±0,05 % related to end of signal range (10 V)
Temperature	50 ppm/K
Load Influence	≤ ±15 mV
Last	≥ 10 kΩ

Interfaces

USB

Function	Übertragen von Konfigurationsdaten und Geräteinformationen
Communication	Via device and setup software
Transmission standard	USB 2.0
Plug Type	Micro-B
Power	≤ 500 mA
Cable length	≤ 5 m

RS485

Function	Übertragen von Prozessdaten, Konfigurationsdaten und Geräteinformationen
Communication	Über Modbus-Master
Galvanic isolation	Funktional
Data transmission	Seriell
Transport	Modbus RTU
Data format	8-1-none^a 8-1-odd 8-1-straight 8-2-none
Data rate	9600 Baud 19200 Baud 38400 Baud^a 57600 Baud 115200 Baud
Minimum response time	0 to 500 ms
Device Address	1 to 254

^a Default setting

SPE

Function	Transmission of process data, configuration data and device information, power supply via PoDL
Communication	Via end device and JUMO Cloud, Modbus-Master
SPE-Standard	10BASE-T1L
Transmission protocol	Modbus TCP, Integrated JUMO Cloud-Gateway
Data rate	10 Mbit/s

Display

Typ	TFT-Display
Size Display Screen diagonal	35,04 mm × 28,03 mm 1,77″
Resolution	128 × 160 px RGB
Brightness	11 Tiers (configurable))

Environmental impact

Permissible ambient temperature With CO₂-Modul

With Display

-40 to +80 °C

-10 to +60 °C

-20 to +60 °C

Permissible storage teperature With CO₂- Modul

With Display

-40 to +80 °C

-30 to +70 °C

-30 to +60 °C

Protection

DIN EN 60529

IP65

Installation height max.

5300 m above NN

Climatic conditions Climat class

Relative humidity

DIN EN IEC 60721-3-3 3K24

≤ 100 % (95 % with CO₂-Modul), non-condensing

Electromagnetic compatibility (EMC)) Emission

Stability

DIN EN IEC 61326-2-3:2022

Klasse B^a Industrieanforderung

Vibration deflection

Acceleration

DIN EN 60068-2-6

0,15 mm from 10 to 58,1 Hz

20 m/s² from 58,1 to 150 Hz

Shockb Peak Acceleration

Shock Duration

DIN EN 60068-2-27

150 m/s²

11 ms

^a The product is suitable for industrial use as well as for household and small businesses.

b The CO2 module is sensitive to vibrations. In the event of vibrations, the measurement result may change due to the design.

Mechanical Properties

Materials Case

Displaycover

PC PMMA

Weight

Ca. 200 g
